Description
This is a new charger that takes the podium in terms of versatility. In addition to wide compatibility, it has also been packed with advanced features, making it one of the best chargers in our range.
The UC4200 charger focuses on maximum compatibility - we can charge any Ni-MH rechargeable batteries of the following sizes: R6 AA, R03 AAA, R14 C, SC, R20 D and 9V batteries. In addition, the UC4200 also supports 3.6/3.7V Li-ion batteries, their high-voltage alternative - Li-HV, whose nominal voltage is 3.85V, and Li-FePO4 batteries. In the case of lithium-based batteries, the charger will support sizes such as: 10440, 14500, 14650, 17500, 17670, 18350, 18500, 18650, 20700, 21700 - also protected, 22650, 25500, 26500, 262650, 3 33600, 16340 R-CR123e . The maximum range of the sled is up to 76 mm, which will ensure the possibility of charging the increasingly popular 20700 and 21700 batteries in the version with electronic protection.
Li-ion/Li-HV and LiFePO4 batteries are charged very accurately using the CC/CV method with a completion of approx. 100mA. This ensures complete safety and complete charging of every battery, even if it is severely weakened or has a low capacity.
Ni-MH and 9V batteries are charged using the CC (constant current) method with very accurate dV/PVD detection - charging is completed only when the maximum voltage on the battery is reached (the value of this voltage may be different for each battery).
Technical information
- four operating modes - charge, discharge, refresh, capacity test, - the last 3 functions are only available for chargers with channel 4
- very accurate measurement of internal resistance (IR)
- support for all popular cylindrical cells - including so-called - called FLAT TOP - with flat plus and 20700/21700 batteries with protection , the maximum cell length is up to 76 mm!
- 0.00 V battery recovery function - the charger can revive almost any battery,
- microprocessor-controlled intelligent, precise charging process CC / CV for Li-ion / Li-FePO4 and CC with dV / PVD for Ni-MH and 6F22 / 9V ,
- support for protected cells (with PCB) and unprotected, also with flat plus Flat Top,
- adjustable charging current for lithium cells: 4x 0.2A/0.5A/0.8A/1A/1.5A or 2x 2A (only for channels 1 and 4), for Ni-MH we have a choice of charging currents such as: 4x 0.2A/0.5A/0.8A/1A, for 6F22/9V batteries the charging currents are 60mA or 120mA,
- discharge currents are 200mA / 400mA,
- a large, legible display with illumination shows all the most important values in real time,
- six independent charging channels: four channels for cylindrical cells and two channels for 9V batteries, with the possibility of charging individual batteries and unusual, strange combinations,
- set of protections : against overcharging, against excessive discharge of cells, short circuit, overload, thermal, against reverse polarity of cells.
